MD1500 Arc Coating Equipment for Saw Blade Coating
15 +
Years Experience
700 +
Installations Worldwide
OEM
Solutions Available
30 +
Countries & Regions
Higher Capacity for Mass Production
MD1500 is designed for manufacturers with higher coating output needs, supporting large batch production with stronger loading capacity.
16 Arc Sources for Efficient Deposition
Equipped with 16 arc sources, MD1500 supports high deposition efficiency, stable coating performance, and improved production output.
Stable Side Ion Etching Before Coating
The third-generation side ion source helps improve surface cleaning, activation, and coating adhesion before deposition.
Automatic Control for Production Efficiency
Touch-screen operation, recipe storage, production records, alarms, and automatic process control make daily coating production easier.
-
16 arc sources
-
1.9 m³ chamber volume
-
12 trees loading capacity
-
Stable coating quality
-
Efficient deposition
-
Higher productivity for large batches
Model No. |
MD1500 |
| Coating Technology | Arc Ion Plating |
| Number of Arc Sources | 16 |
| Equipment Dimensions (mm) | L4850 × W2300 × H2700 |
Chamber Volume (m³) |
1.9 |
Effective Coating Area (mm) |
Φ720 × 900 |
Maximum Working Temperature (°C) |
600 |
Capacity (trees) |
12 |
| Maximum Loading Weight (kg) | 1500 |
| Spindle diameter (mm) | Φ130 |
| Process Time (h) | AlTiN 6–8 |
