    HD500 Composite Ion Coating Equipment - Advanced Technology from China Suppliers and Factory for Superior Film Durability

    ,

    The HD500 is an innovative product developed by our leading factory in China, utilizing cutting-edge composite coating technology. This advanced platform integrates high-ionization sputtering and arc processes, creating a versatile framework that excels in producing films with superior properties. Particularly, the HD500 exhibits remarkable benefits when applied to hard-to-machine materials such as stainless steel and titanium alloys, significantly enhancing their service life.

    ,

    As one of the top suppliers in the industry, we recognize the potential for ongoing advancements in coating processes. The HD500's exceptional flexibility allows it to cater to both small-scale production needs and the demands of process research and development, making it an ideal choice for diverse applications. Trust our China-based factory to provide you with top-quality solutions that meet your specific requirements.

    ,
      Contact us

      Product Advantage

      High deposition rate

      The current density of the arc spot is as high as 1012A/m2, and the energy density is as high as 1013W/m2. The high energy density directly leads to the transformation of the target material at the arc spot from solid phase to metal vapor plasma.

      High ionization rate

      Arc discharge is generated between the cathode evaporation source and the shell, and glow discharge is generated between the workpiece base and the shell, causing the cathode target to evaporate and ionize, generally up to 60-80%.

      efficient and convenient

      Fully automatic coating system, efficient and reliable, capable of batch production 4-5 times a day, equipped with historical records, storable process recipes, offline editing, abnormal alarm, and touch screen operation.

      High impact resistance

      The film has moderate hardness, film adhesion, high rigidity, and good impact resistance, suitable for rough machining.

      Product characteristics

      • Product characteristics
        Capability for fast delivery (Get the shortes production process)
      • Product characteristics
        Customized individually
      • Product characteristics
        High stability (More than 10 years ofproduction experience)
      MD Equipment-Arc PVD Coating

      Workpiece:

      42CrMo (38-42HRC)

      GB：42CrMo

      ASME：4140

      JIS：SCM440

      Cutting data：Blind Hole Drilling

      Cutting speed Vc = 70m/min

      Feeding Fn = 0.15mm/r

      Cooling：External cooling, Emulsion

      MD Equipment-Arc PVD Coating (3)

      Result：

      Huasheng's HPD130 coated tool can achieve a cutting life of 63 meters

      The coated tool from competitor BHE offers a cuttinglife of 49 meters。

      The cutting life has been improved by 28.6%

      MD Equipment-Arc PVD Coating (1)
      MD Equipment-Arc PVD Coating (10)

      Product Parameter

      Product Details

      Max Temperature
      700 ℃
      Coating Tech
      Composite Tech
      Max Loading Weight
      300 KG
      AlTiN Process Time
      6 ~ 8 h
      Name Parameter
      Coating technology Brand-new composite coating technology
      Etching Lateral ion source (hot filament)
      Multi-arc sources (number) 6
      Magnetron cathodes (number) 1
      Equipment size (mm) length 3400 * width 1600 * height 2600
      Chamber volume (m³) 0.7
      Effective coating area (mm) Ф410 * 400
      Maximum working temperature (℃) 700
      Loading capacity (number of trees) 5
      Blade loading (APMT1135) 6000pcs
      Rod blade loading capacity (D4*50L) 1800pcs
      Maximum loading weight (KG) 300
      Shaft diameter Ф130
      Process time AlTiN: 6~8h
      Frequently Asked Questions (FAQ)
      What coating technology is used in this equipment?
      This equipment utilizes a brand-new composite coating technology designed to deliver superior durability, adhesion, and high-performance surface treatments.
      What is the maximum working temperature of the machine?
      The system can operate up to a maximum working temperature of 700℃, making it highly suitable for high-temperature deposition processes.
      How many arc sources and magnetron cathodes does it feature?
      The system is configured with 6 multi-arc sources and 1 magnetron cathode, ensuring excellent coating uniformity and high deposition rates.
      What is the loading capacity for blades and rods?
      The machine can hold up to 6,000 pieces of APMT1135 blades or 1,800 pieces of D4*50L rod blades, with a maximum overall weight capacity of 300 kg.
      What is the typical process time for AlTiN coatings?
      For standard AlTiN (Aluminum Titanium Nitride) coatings, the process cycle typically ranges between 6 to 8 hours depending on thickness and configuration.
